Tap Favorite support

Download the user manual, read FAQs or contact us if you need more help.

User Manual

User Manual

FAQs

Usage

Tap Favorite can be used as a tap tempo switch with BigSky, DIG, DecoFlint, Mobius, and TimeLine. To set up your tap Favorite for Tap Tempo mode, follow these steps:

  1. Unscrew the four screws on the bottom of the chassis.
  2. Once opened, locate the small jumper underneath the circuit board and switch it from the center and right pins to the center and left pins. Please see the image below.

Tap Favorite - Tap Tempo mode - Favorite mode
Once you have the Tap Favorite configured to Tap Tempo Mode you still need to make sure your Strymon Flint, TimeLine, or Mobius pedal is set up to recognize an external tap tempo pedal.

Flint/DIG

Power up while making sure that both conditions below apply:

    1. Both toggle switches are in the DOWN position
    2. You are pressing both footswitches simultaneously (this configures the Flint EXP jack for use with an external TAP pedal; see page 5 of the Tap Favorite user manual).

Deco:

Step 1 Power up holding BOTH footswitches.
Step 2 While holding down both footswitches (this is on page 7 of the Deco user manual):

  1. Turn the SATURATION knob to the 12 o’clock noon position to use Tap/Favorite as a Tap tempo switch to control the LAG TIME of the Doubletracker.

TimeLine/BigSky/Mobius:

    1. Press and hold the Value knob for 2 seconds to access the Globals menu.
    2. Scroll through the menu options until you see EXP MD (this stands for “expression model”).
    3. Once there, press down on the VALUE knob.
    4. Then set the mode for TAP. Press the TYPE knob to exit the Global menu.

This information is also on page 6 of the Tap Favorite user manual.

Tap Favorite can be used as a Favorite preset select switch with Brigadier, Deco, DIGEl Capistan, Flint, and Lex.

By default, Tap Favorite ships from the factory in Favorite mode. You do not need to adjust the internal jumper on Tap Favorite unless you had already switched to Tap Tempo mode.



To switch back to Favorite mode:

  1. Unscrew the four screws on the bottom of the chassis.
  2. Once opened, locate the small jumper underneath the circuit board and switch it from the center and left pins to the center and right pins. Please see the image below.

Tap Favorite - Tap Tempo mode - Favorite mode
Once you have your Tap Favorite configured to Favorite mode, you still need to make sure your Strymon Brigadier, El Capistan, Flint, or Lex is configured to recognize the switch.



Favorite Mode setup for Brigadier, DIG, El Capistan, and Flint:

Step 1 Set both toggles to the middle position.
Step 2 Power up holding both footswitches.
Step 3 Your pedal is now set up to recognize an external favorite switch (this is all on page 3 of the Tap Favorite user manual).

Favorite Mode setup for Deco:

Step 1 Power up holding BOTH footswitches.
Step 2 While holding down both footswitches (this is on page 7 of the Deco user manual):

  • Turn the SATURATION knob full clockwise to use Tap Favorite as a Favorite preset select switch

Favorite Mode setup for Lex:

Step 1 Power up holding BOTH footswitches.
Step 2 While holding down both footswitches (this is on page 4 of the Tap Favorite user manual):

  • Turn TOPMOST LEFT KNOB full clockwise to use Tap Favorite as a Favorite preset select switch
  • OR – Turn TOPMOST LEFT KNOB to 12 o’clock to use Tap Favorite as an external rotary speed switch.

Tap Favorite has been discontinued and replaced with MiniSwitch.

They are nearly identical, aside from the name, and how the footswitch operates. MiniSwitch operates on the down press of the footswitch, Tap Favorite operates on the release of the footswitch. This change was made to ensure the smoothest operation as an external Boost switch with our new Riverside drive pedal.

Learn more about MiniSwitch.

Specs

Tap Favorite is 2″ W x 2.25″ D x 1.8″ H.

No. When used in Tap Tempo mode, the LED will not blink in time with the tempo of the pedal it is connected to.

TAP FAVORITE can used as a preset select switch (FAVORITE MODE) or an external tap tempo switch (TAP TEMPO MODE).

Products that support FAVORITE MODE:

Brigadier, Deco, DIG, El Capistan, Flint, Lex, Riverside

Products that support TAP TEMPO MODE:

Deco, DIG, Flint, Mobius, TimeLine.

Tap Favorite offers selectable Tap Tempo mode and Favorite switch mode, in a very compact package. Tap Favorite can be used as an external tempo switch with TimeLine, Mobius, and Flint, and can be used as favorite preset select switch with Brigadier, El Capistan, Lex, and Flint.  A 1/4″ TRS cable is included.

Favorite switch offers favorite preset select capability for Brigadier, El Capistan, Lex, and Flint, in a size that matches your Strymon pedal. A 1/4″ TRS cable is included.

Warranty

Strymon Non-Transferrable Limited Warranty

Warranty

Strymon warrants the product to be free from defects in material and workmanship for a period of one (1) year from the original date of purchase. If the product fails within the warranty period, Strymon will repair or, at our discretion, replace the product at no cost to the original purchaser.

Exclusions

This warranty covers defects in manufacturing discovered while using this product as recommended by Strymon. This warranty does not cover loss or theft, nor does the coverage extend to damage caused by misuse, abuse, unauthorized modification, improper storage, lightning, or natural disasters. Damage caused by any of the above circumstances may result in a non-warranty repair fee.

Limits of Liability

In the case of malfunction, the purchaser’s sole recourse shall be repair or replacement, as described in the preceding paragraphs. Strymon will not be held liable to any party for damages that result from the failure of this product. Damages excluded include, but are not limited to, the following: lost profits, lost savings, damage to other equipment, and incidental or consequential damages arising from the use, or inability to use this product. In no event will Strymon be liable for more than the amount of the purchase price, not to exceed the current retail price of the product. Strymon disclaims any other warranties, express or implied. By using the product, the user accepts all terms herein.

How to Obtain Service Under this Warranty

For North American customers: Contact Strymon through our website at http://www.strymon.net/support for Return Authorization and information. Proof of original ownership may be required in the form of a purchase receipt.
For International Customers: Contact the Strymon dealer from which the product was purchased from in order to arrange warranty repair service.

Your warranty is valid in the region of purchase. For example, if you buy your product in Japan, any service-related issues will need to be handled in Japan. Only products purchased in the United States can be repaired in the United States.
